PRODUCT




SG0 Class(Horizontal scroll)

SG0 Class
Model Casing Diameter
[mm]		 Jaw Capacity
[ℓ]		 Length
[mm]		 Weight
[kg]
S780 900 / 820 170 4,290 5,750
S880 1,000 / 920 190 4,370 5,950
S1080 1,200 / 1,120 210 4,470 6,850


SG1 Class(Horizontal scroll)

SG1 Class
Model Casing Diameter
[mm]		 Jaw Capacity
[ℓ]		 Length
[mm]		 Weight
[kg]
S1180 1,300 / 1,220 230 5,330 8,000
S1350 1,500 / 1,400 400 5,790 10,300
S1630 1,800 / 1,680 730 5,875 11,300


SG2 Class(Horizontal scroll)

SG0 Class
Model Casing Diameter
[mm]		 Jaw Capacity
[ℓ]		 Length
[mm]		 Weight
[kg]
S1810 2,000 / 1,880 970 5,800 13,850
S2010 2,200 / 2,080 1,450 6,000 17,000
S2310 2,500 / 2,380 2,250 6,105 18,500
S2580 2,800 / 2,640 3,050 6,215 19,600
S2710 3,000 / 2,840 3,900 6,325 20,300


SG3 Class(Horizontal scroll)

SG1 Class
Model Casing Diameter
[mm]		 Jaw Capacity
[ℓ]		 Length
[mm]		 Weight
[kg]
S2980 3,200 4,700 7,200 28,000
S3170 3,400 5,550 7,300 29,200
S3310 3,600 6,800 7,400 31,000
