Standard Type(Horizontal scroll)
 |
Model | Casing Diameter [mm] |
Jaw Capacity [ℓ] |
Length [mm] | Weight [kg] | ||
|---|---|---|---|---|---|---|---|
| Single | Double | Single | Double | ||||
| H1050S | 1,200 / 1,120 | 340 | 4,784 | 3,715 | 4,700 | 4,200 | |
| H1350S | 1,500 / 1,400 | 830 | 4,956 | 3,881 | 5,600 | 5,100 | |
| H1600S | 1,800 / 1,680 | 1,000 | 5,251 | 4,176 | 6,300 | 5,800 | |
| H1800S | 2,000 / 1,880 | 1,150 | 5,488 | 4,413 | 6,900 | 6,400 | |
Heavy Duty Type(Horizontal scroll)
 |
Model | Casing Diameter [mm] |
Jaw Capacity [ℓ] |
Length [mm] | Weight [kg] | ||
|---|---|---|---|---|---|---|---|
| Single | Double | Single | Double | ||||
| H1350A | 1,500/1,400 | 800 | 5,114 | 4,241 | 7,000 | 6,300 | |
| H1600A | 1,800 / 1,680 | 1,060 | 5,211 | 4,338 | 8,000 | 7,300 | |
| H1800A | 2,000/1,880 | 1,200 | 5,303 | 4,430 | 8,700 | 8,000 | |
| H1800B | 2,000 / 1,880 | 1,200 | 6,042 | 5,097 | 10,500 | 9,500 | |
| H2250B | 2,500 / 2,380 | 1,800 | 6,231 | 5,286 | 13,100 | 12,100 | |
| H2750B | 3,000/2,840 | 2,300 | 6,440 | 5,495 | 15,500 | 14,500 | |
| H3300C | 3,600 / 3,420 | 7,500 | 7,765 | 6,820 | 26,800 | 25,800 | |
X-Link Operating Type(Horizontal scroll)
 |
Model | Casing Diameter [mm] |
Jaw Capacity [ℓ] |
Length [mm] | Weight [kg] | ||
|---|---|---|---|---|---|---|---|
| Single | Double | Single | Double | ||||
| H750R | 900 / 820 | 120 | 3,840 | 3,010 | 2,130 | 1,730 | |
| H1350R | 1,500 / 1,400 | 500 | 5,270 | 4,400 | 5,220 | 4,460 | |
| H1600R | 1,800 / 1,680 | 1,100 | 5,570 | 4,700 | 7,660 | 6,900 | |
| H1800R | 2,000 / 1,880 | 1,400 | 6,030 | 5,050 | 8,640 | 7,810 | |
| H2000R | 2,500 / 2,380 | 1,890 | 6,510 | 5,530 | 9,840 | 9,020 | |
