Casing Tube

Single Wall Casing

osc15

Specification(Horizontal scroll)

Specification
D1 / D2 S B Weight (kg) per Working Length (L)
[mm] 1m 2m 3m 4m 5m 6m 5m
600 / 520 20 40 380 672 993 1,255 1,546 1,838 2,421
700 / 620 20 40 447 789 1,131 1,473 1,815 2,157 2,841
800 / 720 20 40 514 906 1,298 1,690 2,082 2,474 3,258
900 / 820 20 40 580 1,022 1,464 1,906 2,348 2,790 3,674
1,000 / 920 20 40 640 1,133 1,626 2,119 2,612 3,105 4,091
1,080 / 1,000 20 40 690 1,190 1,720 2,260 2,820 3,350 4,420
1,200 / 1,120 25 40 860 1,600 2,340 3,080 3,820 4,560 6,030
1,500 / 1,400 25 50 1,440 2,370 3,300 4,230 5,160 6,090 7,950
1,800 / 1,700 25 50 1,720 2,830 3,950 5,070 6,190 7,310 9,550
1,800 / 1,680 25 60 1,837 2,932 4,026 5,120 6,215 7,309 9,498
2,000 / 1,880 25 60 2,190 3,430 4,670 5,910 7,150 8,390 10,870
2,200 / 2,080 25 60 2,410 3,780 5,140 6,510 7,880 9,250 11,990
2,500 / 2,380 30 60 2,810 4,670 6,530 8,400 10,270 12,140 15,880
2,800 / 2,640 35 80 3,929 6,488 9,047 11,606 14,166 16,725 21,843
3,000 / 2,840 35 80 4,147 6,706 9,265 11,824 14,384 16,943 22,061




Double Wall Casing

osc15

Specification(Horizontal scroll)

Specification
D1 / D2 S1 S2 D B Longitudinal Bars Weight (kg) per Working Length (L)
[mm] [Q'ty] 1m 2m 3m 4m Sm 6m 5m
600 / 520 15 10 13 40 18 433 805 1177 1,549 1,921 2,293 3,037
700 / 620 15 10 13 40 20 509 945 1,381 1,817 2,253 2,689 3,561
800 / 720 15 10 13 40 24 587 1,090 1,593 2,096 2,599 3,102 4,108
900 / 820 15 10 13 40 26 653 1,206 1,759 2,312 2,865 3,418 4,524
1,000 / 920 15 10 13 40 30 724 1,343 1,962 2,581 3,200 3,819 5,057
1,080 / 1,000 15 10 13 40 32 790 1,440 2,155 2,845 3,530 4,210 5,570
1,200 / 1,120 15 10 13 40 36 870 1,620 2,365 3,120 3,870 4,610 6,110
1,500 / 1,400 20 15 13 50 45 1,485 2,520 3,555 4,590 5,625 6,660 8,735
1,800 / 1,700 20 15 13 50 55 1,910 3,505 5,085 6,675 8,270 9,865 13,055
1,800 / 1,680 20 20 18 60 55 2,251 4,023 5,795 7,539 9,293 11,056 14,582
2,000 / 1,880 20 20 18 60 60 2,530 4,600 6,670 8,730 10,800 12,870 17,010
2,200 / 2,080 20 20 18 60 66 2,785 5,065 7,350 9,635 11,920 14,205 18,775
2,500 / 2,380 20 20 18 60 76 3,105 5,710 8,315 10,920 13,525 16,130 21,340
2,800 / 2,640 25 25 27 80 86 4,530 8,335 12,135 15,945 19,755 23,565 31,185
3,000 / 2,840 25 25 27 80 90 4,940 9,015 13,090 17,170 21,250 25,330 33,490
